Mosaic GT-1 45 Titanium Gravel Bike Frameset

Description

GT-1 45: Go Bigger. Ride Harder. Demand the best.

It’s no surprise that the GT-1 45 is one of our most popular models—with the Mosaic mix of butted, oversized titanium tubing and clearance to comfortably run 700x45c tires, it absolutely nails the sweet spot in terms of do-whatever versatility and race bike performance. All-day backcountry adventures? Check. Sweet singletrack? No problem. Epic gravel race podium? Local cyclocross series? If you have the watts, the GT-1 45 will get you there. The only thing the GT-1 45 won’t do is compromise.

Compared to the GT-1 AR, the GT-45 has a longer wheelbase to facilitate the added tire clearance and add off-road stability, and oversized tubing to increase stiffness with minimal impact on ride compliance due to the larger tires.

As our top-end gravel machine, the GT-1 45 is replete with our light and lively rider-tuned, butted titanium tubeset and available with custom geometry, painted finishes and other options. Want fully integrated cables? We do that too. Check out the GT-1 i45.

Frameset Features

• Custom T3A/2.5V Double Butted Titanium Tubeset
• Rider Specific Geometry
• 700x45mm Tire Clearance
• Chris King Inset 7 Headset
• 44mm Headtube
• 68mm BSA Bottom Bracket
• 27.2 Seatpost Diameter
• Clamp-On Front Derailleur Mount
• Flat Mount Brake Mounts
• External Mechanical, Internal Di2, or Wireless AXS shift routing
• Choice of Mosaic Painted Finish
• 12×100 Front // 12×142 Rear UDH
• Gravel Chainline
• Internal Downtube Brake Routing

Made To Order Lead Time : 8 Weeks
Made to order from scratch including custom geometry, configuration and choice of finishwork.

Additional Options

• Rack Mounts
• Fender Mounts
• Pump Peg
• Extra H20 Mounts
• Chain Hanger
• 27.2 & 31.6 Seatpost Diameters
• Braze-On Front Derailleur Mount
• Mosaic Artist Series Finishwork*

* options at additional cost.
