Synthesis Alloy E-bike Rims

Tuned Front and Rear Alloy Wheel System for e-mtb riding and racing.

Front and rear specific wheels tuned and optimized to address the specific performance requirements and loads of mountain bike riding.

Compliant tuned front wheel improves handling and maximizes grip and control in turns. Wider inner rim width supports wider tire profile in front, increased volume and contact patch, and rounds tire profile to enhance turning.

Stiff tuned rear wheel supports peak loads and enhances stability and tracking at speed. Narrower inner rim width supports narrower tire profile in rear, improves rolling resistance, and sharpens tire edge for grip.

Welded and sleeved rim joint for additional strength.

Rims sold individually not in sets.

Specs

• ETRTO: 585mm (27.5) / 622mm (29)
• Rim material: 6013 T6 Alloy
• Inner rim width: 31.5mm (27.5 and 29) / 35.5mm (27.5+)
• Outer rim width: 36.5mm (27.5 and 29) / 40.3mm (27.5+)
• Rim height: 21mm
• Spoke holes: 28 (front) / 32 (rear)
• Weights: 928g (27.5+, front), 980g (29, front), 1174g (27.5, rear), 1181g (27.5+, rear), 1238g (29, rear)
